Misura la distanza media tra i centri delle due bobine a bilancia scarica, con striscia posta sui sostegni, in posizione orizzontale. Quanto vale? Come hai proceduto?
Topic: Electromagnetism Metodi: Physical Modeling, Free-Body Diagram Competenze: Measurement & Instrumentation, Physical Reasoning Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Measure the average distance between the centres of the two discharge-balance coils, with a strip on the supports, in a horizontal position. How much is it worth? How did you do?
Topic: Electromagnetism Metodi: Physical Modeling, Free-Body Diagram Competenze: Measurement & Instrumentation, Physical Reasoning Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Usa la striscia di plastica come se fosse una normale bilancia a bracci, e la parte restante del foglio di alluminio, che puoi ritagliare e piegare come meglio credi. Per mezzo del punto per cucitrice, di massa g, determina la massa (in grammi) di ogni centimetro quadrato del foglio di alluminio, assumendo che questo sia di spessore uniforme. Quanto vale? Come hai proceduto?
(Domande 1, 2 – 40 punti. Risposte a pag. 1)
Topic: Newtonian Mechanics, Elasticity & Materials Metodi: Free-Body Diagram, Error Propagation, Physical Modeling Competenze: Measurement & Instrumentation, Error Propagation Objects: Lever Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Use the plastic strip as if it were a normal arm balance, and the rest of the aluminum foil, which you can cut and fold as you please. By means of the sewing point, of mass g, it determines the mass (in grams) of each square centimetre of aluminium foil, assuming that it is uniform in thickness. How much is it worth? How did you do?
(Questions 1, 2 40 points. The Commission shall adopt implementing acts in accordance with Article 21 of this Regulation. 1)
Topic: Newtonian Mechanics, Elasticity & Materials Metodi: Free-Body Diagram, Error Propagation, Physical Modeling Competenze: Measurement & Instrumentation, Error Propagation Objects: Lever Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Disponi via via i pesi campione sulla bilancia e regola la corrente per mezzo del reostato, fino ad ottenere l’equilibrio. Non superare la corrente di A, per non scaricare troppo la batteria. Riporta in una tabella le misure della corrente ed il corrispondente numero di campioni. Dai tuoi dati sperimentali, ricava una formula che rappresenti la relazione tra ed . Se nella formula compaiono delle costanti, precisane il valore e l’unità di misura.
Topic: Electromagnetism, Circuits Metodi: Experimental Data Analysis, Graph Linearization, Physical Modeling Competenze: Experimental Data Analysis, Graph Linearization Objects: Coil, Resistor, Battery Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Dispose the sample weights on the balance and adjust the current through the reostate until balance is achieved. Do not exceed the current of A, so as not to discharge the battery too much. Report the current measurements and the corresponding sample number in a table. From your experimental data, it draws a formula that represents the relationship between and . If constants appear in the formula, specify the value and unit of measurement.
Topic: Electromagnetism, Circuits Metodi: Experimental Data Analysis, Graph Linearization, Physical Modeling Competenze: Experimental Data Analysis, Graph Linearization Objects: Coil, Resistor, Battery Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Dai tuoi dati sperimentali, ricava una formula che rappresenti la relazione tra l’intensità della forza elettrodinamica e l’intensità di corrente . Se nella formula compaiono delle costanti, precisane il valore e l’unità di misura.
(Domande 3, 4 – 80 punti. Risposte a pag. 2 e 3)
Topic: Electromagnetism, Magnetism Metodi: Experimental Data Analysis, Biot-Savart Law, Physical Modeling Competenze: Experimental Data Analysis, Mathematical Modeling Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
From your experimental data, it draws a formula that represents the relationship between the electrodynamic force intensity and the current intensity . If constants appear in the formula, specify the value and unit of measurement.
(Questions 3, 4 80 points. The Commission shall adopt implementing acts in accordance with Article 21 of this Regulation. 2 e 3)
Topic: Electromagnetism, Magnetism Metodi: Experimental Data Analysis, Biot-Savart Law, Physical Modeling Competenze: Experimental Data Analysis, Mathematical Modeling Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Predisponi l’apparecchiatura in modo che la forza tra le bobine sia attrattiva. Quali modifiche apporti all’apparecchiatura? Disegna il circuito.
Circuit diagram for coil series connection
Topic: Electromagnetism, Circuits Metodi: Physical Modeling, Free-Body Diagram Competenze: Diagrammatic Reasoning, Physical Reasoning Objects: Coil, Battery Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Set the equipment so that the force between the coils is attractive. What changes are you making to the equipment? Draw the circuit.
The following table shows the number of units of the vehicle:
Topic: Electromagnetism, Circuits Metodi: Physical Modeling, Free-Body Diagram Competenze: Diagrammatic Reasoning, Physical Reasoning Objects: Coil, Battery Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Riporta in una tabella le misure della corrente ed il corrispondente numero di campioni, con forza attrattiva.
Topic: Electromagnetism, Magnetism Metodi: Experimental Data Analysis, Physical Modeling Competenze: Experimental Data Analysis, Measurement & Instrumentation Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Report the current measurements and the corresponding sample number in a table, with attractive force.
Topic: Electromagnetism, Magnetism Metodi: Experimental Data Analysis, Physical Modeling Competenze: Experimental Data Analysis, Measurement & Instrumentation Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Avrai notato che l’equilibrio della bilancia è più difficile da ottenere con forza attrattiva. Come spieghi questa difficoltà?
Topic: Electromagnetism, Newtonian Mechanics Metodi: Physical Modeling, Free-Body Diagram Competenze: Physical Reasoning, Diagrammatic Reasoning Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
You may have noticed that balance of the balance is more difficult to achieve with attractive force. How do you explain this difficulty?
Topic: Electromagnetism, Newtonian Mechanics Metodi: Physical Modeling, Free-Body Diagram Competenze: Physical Reasoning, Diagrammatic Reasoning Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Individua qualche accorgimento per rendere più agevole la misurazione della corrente necessaria per l’equilibrio. Hai a disposizione spessori di plastica e di carta, che possono aiutarti. Descrivi brevemente come hai proceduto.
(Domande 5, 6, 7, 8 – 80 punti. Risposte a pag. 4)
Topic: Electromagnetism, Newtonian Mechanics Metodi: Physical Modeling, Experimental Data Analysis Competenze: Measurement & Instrumentation, Physical Reasoning Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
Identify some approaches to make it easier to measure the current needed for balance. You have thicknesses of plastic and paper at your disposal, which can help you. Briefly describe how you did it.
(Questions 5, 6, 7, 8 80 points. The Commission shall adopt implementing acts in accordance with Article 21 of this Regulation. 4)
Topic: Electromagnetism, Newtonian Mechanics Metodi: Physical Modeling, Experimental Data Analysis Competenze: Measurement & Instrumentation, Physical Reasoning Objects: Coil Fonte: Testo (PDF) — p.3 Soluzione: Soluzioni (PDF)
